Vertical Curved Rail and Conveyor

Made of high-quality alloy steel, the curved rail is forged through a special hot forging process and nitrided to a surface hardness of HRC60, which enhances wear resistance and service life. The innovative dual-rail structure ensures excellent positioning accuracy of ±0.02mm, minimizing the risk of product jamming during vertical and curved transport. The conveyor belt adopts a multi-layer composite structure that combines a high-strength aramid fiber core with an anti-static PVC surface, which can continuously convey items weighing up to 800 kg even at high speeds.

In the automotive parts manufacturing industry, 70% of leading factories have adopted similar systems to handle the vertical conveying of engine components, increasing production line efficiency by 35%. In the field of electronic assembly, the anti-static and dust-proof design of our conveyor meets the requirements of ISO Class 5 clean rooms, and 50% of electronic manufacturers rely on it to convey delicate circuit boards. At the same time, in the e-commerce logistics industry, it can achieve seamless vertical and curved delivery of packages, helping warehouses improve sorting efficiency by 40%.
