Special-shaped structure triangle series chain circular guideway conveyor

Triangle curved guide rail conveyor. Unconventional special-shaped structure series, mainly triangle, trapezoid, round, etc., because of the particularity of the shape, generally use the bottom plate structure to ensure the overall stability of the line body.

Structural Features

Shape- Triangle

Base structure

Precision chain drive

Light load V-shaped guideway

Application characteristics

* Commonly used Circular guideway diameter is 255-600mm, the parameter table of the Circular guideway can refer to our 《GMP Series Products》.

* We provide 25mm, 44mm, 76mm these three specifications of guide rail for you to choose.

* Speed is related to load size, circular guideway size and off-load condition.

* The Angle of the turn and the shape of the line body can be customized according to the need to communicate.

* Optional ranges of repeated positioning accuracy are: ±0.05-±0.5mm，Accuracy and track specifications are matched.
