76 Series rectangular base plate structure chain circular guideway conveyor

Rectangular circular guide rail conveyor curved guideway chain conveyor

76 Series rectangular base plate structure chain driven circular guideway conveyor, curved guide rail conveyor is used in the automated production and manufacturing process of high load, high speed, high precision, medium and long distance transportation needs.

Customize or Not: Customization

Shape of Conveyor: Rectangular

Single Workstation Load: 50 kg

Width of Guideway: 76mm

Installation Mode: ["Horizontal installation"]

Drive Module: Chain Drive

HOTLINE

15016006490

online consultation Get the quotation

76 Series rectangular base plate structure chain driven circular guideway conveyor, curved guide rail conveyor is used in the automated production and manufacturing process of high load, high speed, high precision, medium and long distance transportation needs. The ﬂexibility of space applications is high.

Structural Features

Shape- Rectangular

Base structure

Precision chain drive

Servo motor drive

Application characteristics

Suitable for long-distance transportation, the circumference can reach more than 100 meters.

Suitable for light load conveying, the maximum load of a single slide seat is 50 kg.

The slide seat works intermittently and can be switched at different speeds as needed.

Optional ranges of repeated positioning accuracy are: ±0.1-±0.5mm
