Special-shaped structure circular series chain circular guideway conveyor

Circular curved guide rail conveyor. Unconventional special-shaped structure series, mainly Trapezoidal, trapezoid, round, etc., because of the particularity of the shape, generally use the bottom plate structure to ensure the overall stability of the line body.

Structural Features

Shape- Circular

Base structure

Precision chain drive

Application characteristics

* Commonly used Circular guideway diameter is 255-600mm, the parameter table of the Circular guideway can refer to our 《GMP Series Products》.

* We provide 25mm, 44mm, 76mm these three specifications of guide rail for you to choose.

* Speed is related to load size, circular guideway size and off-load condition.

* The Angle of the turn and the shape of the line body can be customized according to the need to communicate.

* Optional ranges of repeated positioning accuracy are: ±0.05-±0.5mm，Accuracy and track specifications are matched.
